型式
Type:

三防漆噴霧閥

使用氣源
Operating Air Source:

4-7Kgf/cm

最小吐出量
Min.Shot Volume:

0.01ml

操作黏度
Operation Viscosities:

1-1.000.000cps

主體材質(zhì)
Wet Body Material:

不銹鋼

入料壓力
Material Input Pressure:

<300 kg

入料口尺寸
Material Inlet Outlet Size:

1/8″npt(f)

操作速率
Operating Cycle:

<400/min

外形尺寸
Overall Dimensions(mm):

21*21*150 (mm)

安裝尺寸
Mounting dimensions:

M4*13 (mm)

※霧化壓力短暫保持，確保噴嘴清理，防止堵塞，保證流體的均勻霧化

※適用于三防漆等中，低粘度流體噴涂（5mm-50mm）（5000cps以下粘度適用）
